Lubratec® Stabidoor

Safety door for intensive use even with high wind loads

Our Lubratec Stabidoor is a sectional door designed to withstand strong wind loads and to cope with the high daily demands, even with intensive use. Especially in dairy farming, in cattle stables, pigsties or even in indoor schools, heavy and sometimes bulky machines and equipment are needed for efficient management and maintenance. These are led into the stable or hall through large gates.

Our Stabidoor is a particularly robust wind protection door that is easy to operate and, thanks to high-quality fabrics, provides reliable protection against external weather influences. Unlike conventional material doors, excellent ventilation effects can be achieved. The wind protection door is characterised by its ideal size for passageways with large agricultural vehicles, such as a tractor. Daily opening and closing even in strong winds is no longer a challenge thanks to lateral guide rails and horizontal tubes. Due to the built-in sealing lips, draughts entering from the side have no route in.

Optimum size for access by large vehicles

Suitable for daily opening and closing

Lubratec Stabidoor

Product benefits

  • Suitable for daily opening and closing
  • Optimum size for access by large vehicles
  • High wind load capacity thanks to horizontal tubes and lateral guide rails
  • Incorporated lip seals to prevent draughts from air infiltration at sides
  • Additional ventilation effect possible with wind protection meshes
  • Fast and cost-effective final assembly due to pre-assembly prior to despatch
Opening directionHanging winds upwards, top pelmet included
Opening heightMax. 6 m
Opening widthMax. 6 m
DriveManual drive, 400 V direct-mount motor, 230 V tubular motor (radio remote control optional)


Building Information Modeling

Download data and plan

You would like to start planning your textile door directly? Then download the BIM data and CAD designs for your individual Stabidoor directly via our new portal. With just a few clicks, you can select the desired drawing in the required format and start the download. If you have any questions during the planning process, please do not hesitate to contact us.

Download BIM & CAD Data
